What Determines the Thickness of A TFT Display?
TFT (Thin-Film Transistor) screens combine the thinness of thin-film technology with the active control provided by transistors. Unlike a graphic or character LCD, a TFT display is an active-matrix display that uses thin-film-transistor technology to enhance image quality, addressability, and contrast. TFT displays can portray more complex data and commands.
Due to the high resolutions and ability to display up to 16.7 million different colors on each pixel, TFT displays are best suited for presenting detailed information and professional designs. Let’s find out the factors that rule the thickness of your TFT module.
Looking to modernize your LCDs?
Differences Between a TFT and a Graphic LCD
TFT displays use an active-matrix design that provides individual transistors for each pixel. This pixel-focused design offers high resolution, vibrant colors, and superior image quality for applications that want a user interface similar to a smartphone. They excel in multimedia tasks due to their wide color range and sharp detail but consume more power.
On the other hand, Graphic LCDs operate on passive matrix addressing, displaying text and simple graphics in monochrome or limited color. They are common in devices like digital watches and industrial equipment. Graphic LCDs offer essential image quality with lower power consumption compared to TFTs. While TFTs are ideal for high-resolution graphics and multimedia, Graphic LCDs are suitable for more straightforward displays where power efficiency and basic image rendering suffice.
You can also upgrade your existing graphic LCD to a TFT.
Components of TFT Displays
Understanding the components of a TFT is the first step in analyzing its thickness.
- Liquid Crystal Layer: Unlike CRT screens, LCD units use liquid crystals as their pixels. This layer, which is still at the center of the display, is where electrical signals cause the orientation of liquid crystal molecules to shift. Changes in their orientation also regulate the way light passes through crystals.
- Glass Substrates: Two glass substrates mechanically support the liquid crystal layer. Electron-transporting conductors are employed on the interior surface of these substrates. Usually, these substrates are tiny to preserve the LCD’s overall small profile.
- Thin Film Transistors (TFTs): TFT is a grid of thin film transistors, typically made from semiconductor materials such as amorphous silicon or polycrystalline silicon. These transistors control the individual pixels on the display, which lets you regulate precise voltage for color and brightness adjustments.
- Polarizing Filters: A layer of liquid crystal molecules between two transparent electrodes makes up each pixel in a TFT display. On either side of the liquid crystal layer are two polarizing filters—one perpendicular and the other parallel. They control the light that comes through the layer of liquid crystal. The axes of light transmission that these filters identify are typically perpendicular.
- Backlighting System: Similar to LCDs generally, TFT modules use a backlighting technology to illuminate the display from behind the liquid crystal layer. LED arrays and edge-lit panels are standard backlighting technologies that illuminate the display surface evenly.
- Controller (Driver Chip): The controller chip converts input signals into an image that appears on the screen, such as video data. These are not your typical character LCDs; thus, you do not need a character mask. They generate dynamic or random images. The microprocessor ensures smooth display performance by controlling refresh rates and pixel activation.
Manufacturing a TFT
Manufacturing a TFT module involves several steps:
- Start with glass substrates cleaned and coated with transparent conductive material to form electrodes.
- Thin film deposition techniques create the thin film transistor (TFT) array on one of the glass substrates. This array comprises thousands or millions of individual transistors, each controlling a pixel on the display.
- Inject liquid crystal material between the two glass substrates, ensuring uniformity and alignment. This liquid crystal layer acts as the medium through which light is modulated to produce images.
- Apply color filters and polarizers to one of the glass substrates to achieve full-color reproduction and enhance contrast.
- Integrate a backlighting system, typically LEDs or CCFLs, to illuminate the display evenly from behind.
- Install controller chips into the display module to drive the TFT array, manage data input, and control display functions.
- Seal the edges of the glass substrates together to prevent leakage and protect the internal components.
- Conduct rigorous testing to ensure the display meets performance specifications, including resolution, color accuracy, brightness, and response time.
- Assemble the display module into the final product, whether a smartphone, tablet, monitor, or other electronic devices.
Looking to modernize your LCDs?
Factors Affecting Thickness
Several factors influence the thickness of TFT displays, including:
TFT Array Design
This is the grid or array of transistors that hold the thin films. Compact transistor designs and optimized routing techniques allow for tighter pixel pitches and thinner display profiles. Other integration components also add to the overall thickness of your TFT module.
Display Size
The thickness of the LCD is also influenced by its size. Thicker substrates and backlighting solutions are usually needed for larger displays to preserve uniform illumination and structural integrity. Additionally, a thicker design could be required to safeguard overall stability.
Substrate Thickness
The thickness of the LCD assembly is decreased by thinner glass substrates. An LCD typically has a thickness of between 1.7mm and 3 mm. Usually, each glass substrate contributes 0.7 mm. Technological developments in the glass industry have made it possible to produce thinner and more robust substrates. These days, experiments are being conducted to replace glass entirely with incredibly thin polymer layers.
Liquid Crystal Layer Thickness
The thickness of the liquid crystal layer influences response time, contrast, and other optical characteristics of the display. The fluid layer is typically only a few micrometers thick—1/10th the thickness of an ordinary hair. Also, just roughly 0.3 ml, or six drops of eye medication, is required for a 14″ LCD monitor. Manufacturers work hard to keep this thickness as low as possible without sacrificing ideal display quality. Fewer resources are needed, and a thinner layer provides better crystal control.
Backlighting System
The LCD’s thickness may also be affected by the specific type of illumination that is employed. Comparing slimmer backlighting alternatives to more conventional backlighting techniques, like LED edge lighting, thinner overall profiles are possible. Edge lighting may produce darker areas in the center and brighter corners, particularly in the dark. However, they contribute to creating thinner profiles compared to conventional backlit panels.
Conclusion
Thanks to its high resolutions, vibrant colors, and fast response times, TFTs are among the most popular variety of LCDs today. They can overcome their usage boundaries with a planned design approach for thinner modules and power efficiency.
